The Object Tree & Layer Management

The Object Tree is accessible from the Right Menu (the icon resembling a stack of papers/layers) or instantly via the keyboard shortcut `Ctrl+Shift+O` (Windows) / `Cmd+Shift+O` (Mac).

When you open the Object Tree, you will see a hierarchical list of every visual element currently active on your chart. This includes all drawings, indicators, and the main price symbol itself.

Rather than trying to click a specific trendline that is buried underneath three other drawings and two moving averages on the chart canvas, the Object Tree allows you to select, modify, and manage elements directly from a clean list interface.

Two of the most frequently used functions in the Object Tree are Locking (the padlock icon) and Hiding (the eye icon).

Locking an object prevents it from being accidentally moved, resized, or deleted on the chart canvas. If you have spent 10 minutes perfectly aligning a Fibonacci channel, the very next thing you should do is lock it. Locked objects cannot be dragged by the mouse.

Hiding an object temporarily removes it from the chart canvas without deleting the underlying data. This is crucial when your chart becomes too 'noisy' to read price action clearly. Instead of deleting your hard work, you simply click the eye icon to hide a folder of drawings, analyze the naked price action, and unhide them when finished.

When you draw multiple shapes that overlap—such as a large semi-transparent background rectangle and a specific text callout—you need to control which object appears 'in front' of the other. In design software, this is called the Z-Index.

TradingView allows you to manage this visual priority directly from the Object Tree. The order of items in the list determines their visual stacking on the chart. Items higher up in the Object Tree list will render on top of items lower down in the list.

You can simply click and drag items up or down within the Object Tree to change their layering. Alternatively, you can right-click any drawing on the chart, select 'Visual Order', and choose 'Bring to Front', 'Bring Forward', 'Send Backward', or 'Send to Back'.

Multi-Timeframe Visibility is arguably the single most important organizational feature for professional traders. When you conduct top-down analysis, you draw major structural levels on the Weekly chart, swing levels on the Daily chart, and precise entry triggers on the 15-minute chart.

If all of these drawings were visible at all times, your 15-minute chart would be an unreadable mess of overlapping thick lines from higher timeframes. 'Visibility' solves this.

By double-clicking any drawing (or folder) and navigating to the 'Visibility' tab, you can specify the exact timeframes where that drawing is allowed to appear. You can configure a Weekly trendline to only show on 'Days, Weeks, and Months', ensuring it completely disappears when you zoom into an intraday 'Minutes' chart.

If you use a multi-chart layout (e.g., a 2-chart split showing Nifty on the 1-Hour and 5-Minute simultaneously), you need your drawings to synchronize perfectly between them.

TradingView handles this via the Sync toggle (the globe/chain-link icon on the left toolbar). You can choose to 'Sync drawings in layout' (drawings appear on all charts within the current window) or 'Sync globally' (drawings persist across all your saved layouts).

Crucially, the Object Tree manages how groups synchronize. If you place a drawing inside a synchronized folder, it will adopt the sync properties of that folder. You can also right-click specific drawings in the Object Tree to manually override their sync behavior, keeping certain experimental doodles restricted to a single chart while your main trendlines sync everywhere.

How does a professional Indian equity trader actually use the Object Tree in practice? Here is the exact top-down workflow for analyzing an index like Bank Nifty or a high-beta stock like Reliance.

Step 1: Open the Weekly chart. Draw major support/resistance zones. Select them all in the Object Tree, group them into a folder named 'HTF Zones', and set the folder visibility to 'Days, Weeks, Months'. Lock the folder.

Step 2: Drop to the Daily/1-Hour chart. Draw swing levels, Fibonacci extensions, and volume profile POCs. Group these into a folder named 'Swing Structure'. Set visibility to 'Hours and Days'.

Step 3: Drop to the 5-Minute/15-Minute chart. Draw your intraday scalp levels, VWAP lines, and pre-market highs/lows. Group them into 'Intraday Setup'. Set visibility to 'Minutes' only.

Result: As you switch timeframes during the live trading session, the chart automatically cleans itself. The 5-minute chart shows crisp intraday levels without the clutter of weekly rectangles, yet your core structural analysis remains safely preserved and locked in the background.
